MULTIFUNCTIONAL SUBSURFACE DETECTING

Best Price Guarantee
Worldwide Free Shipping
2 Year Manufacturer Warranty
Made in Germany

Features

All-Arounder: OKM's detector for multifunctional subsurface detecting - including all features.
Depth: Customers found treasures up to 20-25 meters deep.
Use Cases: Treasure hunting, natural gold prospection, tunnel detection.
Operating Modes: Ground Scan, Magnetometer, Pinpointer, Mineral Scan, Tunnel Scan.
Detectable Objects: Treasure chests, cavities, tunnels.

Package Includes

Headphones
User's Manual
Joystick
Control Unit
3D Software ("Visualizer 3D") with Data Cable
Power Pack with Charger and Travel Adapter
Super Sensor
Waterproof and Shock Resistant Pelican Case
Telescopic Rod Assembly
GPR-Antenna (100 cm)
GPR-Antenna (25 cm)
GPR-Antenna (50 cm)
GPR-Antenna (75 cm)
Sensor for Tunnel Detection

Variants:

3D Ground Scanner For Treasure Hunters And Gold Seekers

Are you tired of finding only small objects near the surface? Do you want to detect the real buried treasures which lie deeper than a normal metal detector can detect? OKM introduces the multifunctional sub-surface imaging detector and ground scanner EXP 4500. Developed for treasure hunters as well as prospectors, the eXp 4500 allows to find those buried treasures.

Unlike other ground scanners and imaging detectors, the eXp 4500 is truly unique. Calling the eXp 4500 a simple detector is not justified, due to its multitude of built-in functions, the eXp 4500 can locate buried items, ancient artifacts, lost treasures and naturally occurring mineralization like gold and silver at depths well beyond that of a common metal detector.

Measurement Data In High Resolution

The measurement unit of the EXP 4500 includes a PC-module with which data is displayed immediately on the full color screen. Measured data is stored in the internal memory and can be transferred later to a computer. Transferring measured values to a computer allows the operator to evaluate and compare all stored data. In doing this the operator can determine depth, size and position of targets using the professional Visualizer 3D software.

Characteristics Of The EXP 4500

Lightweight portability
Non-intrusive real time ground surveying
Quick and easy set up and operation
Live color coded surveys
Allows for impromptu and fast surveys
Immediate on-site interpretation of target area
Measured values showing extreme depth of survey
Measured values showing location of targets within surveyed area
Highly sensitive and accurate metal detecting device

Applications Of The EXP 4500 Ground Scanner

The EXP 4500 ground scanner is a high performance metal detecting device which is specially designed for the following applications:

Archaeological 3D surveys, metal detection, treasure hunting and gold prospection
Pin pointer function to locating the exact position of buried treasures and artifacts
3D imaging including size and depth
Detecting gold and other items of great value
Finding ancient artifacts, hidden treasures, gold, silver, bronze, hoards of coins, treasure deposits, pirate chests
Tunnels, voids and cavern locating
Mineral and natural gold prospecting

With several specialized detection antennas, the EXP 4500 ground scanner can also be used in highly mineralized areas for treasure hunting and prospecting.

Special Probes And Antennas

The functionality of the EXP 4500 metal detector is only one key point that makes it a unique treasure hunting unit. Every single probe and antenna is tuned and optimized for its own purpose and function. The following antennas are available:

GPR-Antenna (25cm, 50cm, 75cm, 100cm)
Antenna for tunnel detection
Super Sensor for high resolution ground scans, pin pointing and mineral detection

Operating Modes Of The EXP 4500 Ground Scanner And Metal Detector

Hidden artifacts are of different sizes and made from different materials. So the treasure hunter needs different operating modes and locating methods to find all of those hidden treasures at various depths under the ground surface. The eXp 4500 ground scanner is capable of the following operating modes:

Ground Scan is ideal for treasure hunters and archaeologists looking for underground artifacts, treasures as well as historical and archaeological items
Mineral Scan has been integrated for gold prospectors, seekers and miners, who are looking for natural gold and minerals
Tunnel Scan is a specialized mode to detect underground voids, tunnels, cavities and hollow spaces
Pin Pointer assists you in locating the correct position of detected items
Magnetometer is helpful to locate ferrous metals like iron and steel

Buried Objects Are Indicated By Different Colors In Graphical 3D Representation

EXP 4500 Professional Plus: The Professional Plus Edition of the eXp 4500 metal and ground detector is for professional searching needs and includes all available options. All available probes and antennas like the horizontal GPR antennas (all sizes) as well as the tunnel and cavity antenna are included.

Computer Minimum Requirements

CD-ROM drive: Minimum 4x
Interface (Data Transmission): USB
Free Disk Space: Minimum 50 MB
Working Memory (RAM): Minimum 256 MB
Graphic Card: Minimum 128 MB, OpenGL-compatible
Processor: Minimum 1.2 GHz
Operating System: Windows XP, Windows Vista, Windows 7, Windows 8, Windows 10

Data Transmission

Technology: USB
Maximum Transfer Rate: 115200 Baud

Control Unit

Dimensions (H x W x D): 220 x 160 x 295 mm
Weight: Approx. 1350 g
Input Voltage (Max.): 12 – 14.4 V DC, 22 W Maximum
Processor / Main CPU: 800 MHz, INTEL i586-compatible
Data Memory: 256 MB
Operating Temperature: 0°C – 70°C
Storage Temperature: –20°C – 60°C
Waterproof: No
Operating Time: Approx. 3 hours (delivered power supply full charged, 25°C)
Air Humidity: 5% – 75%
Feedback: Acoustic, visual
Protection Type: IP40
Working Memory: 256 MB RAM
